contact us 0755-295558429238交流風扇
首頁 > 產品展示 > EC交流轉直流風機 > 9238交流風扇
| 可選功能 | 產品編號 | 電壓范圍 | 額定電流 | 功率 | 轉速 | 風量 | 風壓 | 噪音 | ||
| Available | Listed | Operation | Reated | Reated | Reated | Air | Air | Noise | ||
| Functions | Model | Voltage | Current | Power | Speed | Flow | Pressure | Level | ||
|
FG RD RDL LD PWM TP VC RC CS RP SS AS CL IPX8 |
Part NO: | VDC | A | W | RPM | CFM | m3/min | mmAq | InH2O | dBA |
| DF9238B12L | 12 (7-14) | 0.35 | 4.20 | 4000 | 92.18 | 2.36 | 11.65 | 0.35 | 46.7 | |
| DF9238B12M | 0.78 | 9.36 | 5500 | 125.10 | 3.54 | 21.50 | 0.85 | 54.2 | ||
| DF9238B12H | 1.70 | 20.40 | 7000 | 158.02 | 4.47 | 34.22 | 1.35 | 59.3 | ||
| DF9238B12V | 2.60 | 31.20 | 8500 | 179.97 | 5.09 | 44.39 | 1.75 | 63.5 | ||
| DF9238B24L |
24 (15-27) |
0.18 | 4.32 | 4000 | 92.18 | 2.61 | 11.65 | 0.46 | 46.7 | |
| DF9238B24M | 0.42 | 10.08 | 5500 | 125.10 | 3.54 | 21.50 | 0.85 | 54.2 | ||
| DF9238B24H | 0.82 | 19.68 | 7000 | 158.02 | 4.47 | 34.22 | 1.35 | 59.3 | ||
| DF9238B24V | 1.25 | 30.00 | 8500 | 190.95 | 5.40 | 49.97 | 1.97 | 65.8 | ||
| DF9238B48L |
48 (30-57) |
0.09 | 4.32 | 4000 | 92.18 | 2.61 | 11.65 | 0.46 | 46.7 | |
| DF9238B48M | 0.21 | 10.08 | 5500 | 125.10 | 3.54 | 21.50 | 0.85 | 54.2 | ||
| DF9238B48H | 0.41 | 19.68 | 7000 | 158.02 | 4.47 | 34.22 | 1.35 | 59.3 | ||
| DF9238B48V | 0.62 | 29.76 | 8500 | 190.95 | 5.40 | 49.97 | 1.97 | 65.8 | ||
